Customized 200*200mm Portable CO2 Laser Marking Machine 20w 30w With Handicrafts
Description :
1.The imported fiber laser is protected with an isolated layer, effectively lifting its stability and extending its service life.
2. High Precision: Up to 0.0012 mm, bring you the fantastic and satisfied marking effect.
3. Superior Laser Beam: The definition is 1 micron,10 times as that of traditional products.
4. High-quality scan head, with good seal, capable to prevent dust and water, small volume, compact and solid.
5.Low consumption: <500W, is 1/25 ~ 1/10 times as that of Diode and YAG, more economized and environmental.
6. The fiber laser marking machine with a small body, a long service life, and a maintenance-free guarantee is
suitable for any working environment.
7. This industrial marking machine enjoys an excellent manual focusing system and user-friendly operating
structure.
Application
It is mainly used for nonmetal, it can suitable for Craft gifts, leather garments, advertising signs, model
making,food packaging, electronic components, pharmaceutical packaging, medicine packaging, printing
plate, shell plate etc. With Keyboard Laser marker,Glass laser marker, Arts laser marker, bath ware laser
marker, building ceramics, beverage packaging, textile cutting, rubber products, shell plate, electronic
components, leather and other industries.
Technical Parameter :
| product name | mini CO2 laser marking machine |
| Laser power | 10w / 20w |
| Laser wavelength | 1064nm |
| repeat frequency | 20-80KHz |
| Beam quality | M2 <1.5 |
| Engraving depth | ≤0.3mm |
| Engraving line speed | ≤7000mm / s |
| Minimum line width | 0.01mm |
| Standard Marking area | 110 * 110mm |
| Deep marking line | ≤0.2mm |
| Smallest focused spot | 0.005mm |
| The minimum character height | 0.15mm |
| Repeatability | ± 0.001mm |
| Control Interface | USB |
| Laser module life | 100,000 hours |
| Total power consumption | <0.5kw |
| electricity demand | 220V ± 22V / 50Hz / 12A |
| cooling systerm | Precision temperature / closed loop air-cooled |
| operating system | WinXP / Win7/8/10 |
Sample Show :
What is the Packing & Shipping:
1. Standard plywood case, its compressive strength and bearing quality is better.
2. the board area is bit, the soil structure is good, it is better in leak proofness and waterproof.
3.when importing, the plywood case is with fumigation-free, the procedure is simple.
What is Our Service?
Pre-sale Service
1.Supply item design,process design.
2.Help you to chose the suitable machine.
Sale Service
1.Acceptance equipment together with you .
2.Help you to make the method statement and the details of the process.
After Service
1.Guarantee for a 3 years.
2.Quality problem,we will sent you the accessories.
3.Free repair whole using life(without the freight and accessories charge).
